RECESSED MOUNTED PANEL EVO
BACKLIGHT UGR 19
BACKLIGHT UGR 19
40W
Power3000lm
Luminous flux90°
Beam angle
Recessed and Surface Mounted EVO Panels offer Backlight (UGR19), anti-glare lenses, LEDs directed downwards and a high Color Rendering Index (CRI). This product was designed to provide greater lighting comfort to illuminate spaces like work environments and classrooms.
| Luminous efficacy | 75lm/W and 78lm/W |
| CRI (Color rendering index) | >90(R9 >50) |
| UGR (Unified glare rating) | <19 |
| Power factor | >0,92 |
| Lifespan | 25000h |
| Prevailing material | Aluminum |
| Warranty | 2 years |
X
| STH20958/30 | White | 100-240Vac | 3000K | 3000lm | 100-240V |
| STH20958/40 | White | 100-240Vac | 4000K | 3100lm | 100-240V |
Graphics
Documents
Photos
Not added.
Observations
Fixation clips included.
Driver Included.
