ALL LIGHT 12V EVO LED STRIP
CRI 90
CRI 90
10W/m
Power/m700lm/m
Luminous flux/m
EVO, PRO and ULTRA: Stella's new LED Strips line. We present three entirely redesigned series, complete with novel features that are applicable to a variety of projects. All Light EVO LED Strips offer up to 288 LEDs/m, COB technology, high adhesion of 8N/cm² and CRI 90.
| Total power | 50W |
| Luminous flux total | 3500lm |
| LED specifications | 288 LEDs COB/m |
| CRI (Color rendering index) | >90(R9 >40) |
| Adhesion | 8N/cm² |
| Lifespan (L70) | 25000h |
| Roll lenght | 5m |
| Warranty | 2 years |
| Operation temperature | -10 ~ 40°C |
X
| STL24814/27 | 12Vcc | IP20 | 2700K | Warm white | 700lm/m |
| STL24814/30 | 12Vcc | IP20 | 3000K | Warm white | 700lm/m |
| STL24814/50 | 12Vcc | IP20 | 5000K | Neutral white | 700lm/m |
| STL24814/40 | 12Vcc | IP20 | 4000K | Neutral white | 700lm/m |
Video
Graphics
Documents
STELLA - STL24814-27 - Fita All Light EVO IP20 12V 10W.ies
STELLA - STL24814-27-30-40-50 - FITA ALL LIGHT EVO_PACK.zip
STL24814_27_30_40_50.skp
MANUAL_FITA_ALL_LIGHT_12V_EVO_STL24804_STL24814_STL24824_V1.pdf
STELLA - STL24814-30 - Fita All Light EVO IP20 12V 10W.ies
STELLA - STL24814-50 - Fita All Light EVO IP20 12V 10W.ies
STELLA - STL24814-40 - Fita All Light EVO IP20 12V 10W.ies
Observations
- To avoid loses of total luminous flux, don't connect more than 5m of a 12V LED Strip in series.
- The product must only be installed on clean and dry surfaces.
- Allows cutting every 2,08cm.
- It is essential that electrical installations be carried out by qualified professionals
- Use the LED Strip completely unrolled
- To be used with Stella 12V LED Drivers only
