Surface Mounted Profile 24V | 25mm | Flat Black Diffuser

18,5W/m

Power/m

350lm/m

Luminous flux/m

90°

Beam angle

Like the recess mounted profiles, the surface mounted versions of the Archi line have a rectilinear design and homogeneous lighting. Available in options with flat or recessed diffusers, these products are installed with 24V LED strips with, on average, 120LEDs/m, and have a non-apparent fastening system.

* PRODUCTS AVAILABLE WHILE STOCKS LAST.

Total power	18,5W and 37W
Voltage (Vcc)	24Vcc
LED specifications	120 LEDs SMD2835/m
CRI (Color rendering index)	>93(R9 >60)
UGR (Unified glare rating)	18,9
Lifespan (L70)	25000h
Prevailing material	Aluminum
Warranty	2 years
Operation temperature	-10 ~ 40°C

Compare

STH20963PTO/27	Black \| Black diffuser	1m	2700K	350lm
STH20964PTO/27	Black \| Black diffuser	2m	2700K	700lm

Graphics

Documents

STELLA - STH20963PTO-27 - ARCHI - PERFIL DE SOBREPOR PLANO.ies

STH20963PTO_27.skp

STELLA - STH20963PTO-27 - PACK - SKP.zip

Manual Perfil Archi - Sobrepor Versão 5.0.pdf

STH20963PTO_27.rfa

STH20964PTO_27.skp

STELLA - STH20964PTO-27 - PACK - SKP.zip

STH20964PTO_27.rfa

Observations

End caps and fixation clips included.

Indicated accessories:

Linear Splice Kit (STH20976, sold separately)
L Shaped Splice Kit (STH20977, sold separately)
Ceiling-Wall L Shaped Splice Kit (STH20978, sold separately)

STH20963PTO/27, STH20964PTO/27 - Product available while stocks last.

To be used only with Stella's 24Vcc drivers.
